NEW 7 string 25.9V lithium battery protection board with balancing high current 22A Seiko IC AO MOS tube

100 % of buyers enjoyed this product!
Availability: in stock
Price:  $ 30.67 / piece
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Sort By

Top-rated Seller

Share:

7 string 25.9V lithium battery protection board with balancing high current 22A Seiko IC AO MOS tube

& Features:

(1) for each cell-accuracy voltage detection function; (2) three overcurrent detection function; (3) can be controlled by the MOS transistor of the battery charge and discharge; (4) Wide operating temperature range -40 ° C ~ +85 ° C; (5) Low current consumption. & Use: · 7 strings of lithium nickel-cobalt-manganese, cobalt oxide, lithium manganese lithium-ion rechargeable battery pack; · 7 string lithium polymer rechargeable battery pack;

& Technical parameters:

No. Test Item Standard 1 Voltage Charging voltage DC: 31.5V CC / CV Single equilibrium voltage 2 Current Balance current for single Single drain the battery (consumable) ≤ 11uA Maximum continuous discharge current of 8A 3 Overcharge Protection Overcharge detection voltage 4.35V ± 0.025 V Overcharge detection delay time 1.2S Overcharge recovery voltage 4.15 ± 0.05V 4 Over-discharge protection Over discharge detection voltage 2.7 ± 0.080 V Over discharge detection delay time of 50-150ms Over-discharge recovery voltage 3.0V ± 0.1V 5 Over Current Protection Over current detection voltage 200 ± 25mv Overcurrent detection current 8A Overcurrent detection delay time 5ms-15ms Restore state auto-recovery 6 external short circuit protection detection state Detection delay time 200-500us Restore state auto-recovery 7 Resistance protection circuit (MOSPET) ≤ 30mΩ 8 Temperature Operating temperature range -40 ~ +50 Storage temperature range -40 ~ +125 9 Dimensions (L * W * H) 30 * 10 * 2.6MM

Product wiring diagram

Note:

1 Please note that input and output voltage, and load current conditions of use, the power consumption of the protective plate does not exceed the allowable power dissipation specifications; (2) may occur when connecting the battery can not discharge the case, in this case, the connection charge can be restored to normal operation; 3 battery overcharge and over discharge the battery case of mixed state becomes filled with over-discharge state, it is impossible to charge and discharge; (4) The protection board ESD protection circuitry built though, but please do not apply to the protection board protection plate circuit performance over excessive static electricity.

Shipping list:

Lithium battery protection board X1
