NEW 3 series 10.8V 11.1V12.6V 18650 lithium battery protection board electric battery protection circuit 8A work

100 % of buyers enjoyed this product!
Availability: in stock
Price:  $ 74.67 / lot
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Sort By

Top-rated Seller

Share:

3 series 10.8V 11.1V12.6V 18650 lithium battery protection board electric battery protection circuit 8A work

& Features:

(1) for each cell-accuracy voltage detection function; (2) three overcurrent detection function; (3) can be controlled by the MOS transistor of the battery charge and discharge; (4) Wide operating temperature range -40 ~ +85 ; (5) Low current consumption. & Use: · 3 series nickel-cobalt-manganese, lithium cobalt oxide, lithium manganese lithium-ion rechargeable battery pack; · 3 series lithium polymer rechargeable battery pack;

& Technical parameters:

No. Test Item Standard 1 Voltage Charging voltage DC: 15V CC / CV Single equilibrium voltage 2 Current Balance current for single Single drain the battery (consumable) ≤ 8uA Maximum continuous discharge current 8A 3 Overcharge Protection Overcharge detection voltage 4.35V ± 0.025 V Overcharge detection delay time 1S Overcharge recovery voltage 4.15 ± 0.05V 4 Over-discharge protection Over discharge detection voltage 2.7V ± 0.080 V Over discharge detection delay time of 100-150ms Over-discharge recovery voltage 3.0V ± 0.1V 5 Over Current Protection Over current detection voltage 200 ± 25mv Overcurrent detection current 28 ± 1A Overcurrent detection delay time 5ms-15ms Restore state auto-recovery 6 external short circuit protection detection state Detection delay time 200-500us Restore state auto-recovery 7 Resistance protection circuit (MOSPET) ≤ 8mΩ 8 Temperature Operating temperature range -40 ~ +50 Storage temperature range -40 ~ +125 9 Dimensions (L * W * H) 50 * 16 * 2.6 MM

Product wiring diagram

Weld Description:

· B + battery pack connected to the positive; · B1-connected battery 1 and battery 2 contacts; · B2-connected cell 2 and cell 3 contacts; · B3-do not pick; · B-connected to the negative terminal of the battery pack; · P + connection charge / discharge upright pole (charging terminal / discharge side shared); · P-connection charge / discharge end of the negative (charging terminal / discharge side shared). Note: 1 Please note that input and output voltage, and load current conditions of use, the power consumption of the protective plate does not exceed the allowable power dissipation specifications; (2) may occur when connecting the battery can not discharge the case, in this case, the connection charge can be restored to normal operation; 3 battery overcharge and over discharge the battery case of mixed state becomes filled with over-discharge state, it is impossible to charge and discharge; (4) The protection board ESD protection circuitry built though, but please do not apply to the protection board protection plate circuit performance over excessive static electricity.

Shipping list:

Lithium battery protection board X10
