1.Specially designed for small traversing machine, suitable for the following sizes of 280mm frame, especially 130mm internal frame, can play small and functional advantages;
2.This board provides all the functions with a weight of 8G, size only 27*27MM, and a fixed hole of 20MM (M2.5 hole);
3.Designed for four axis models, built in LC filter, support BF firmware (Omnibus, F3 firmware);
4.The use of STM32F303 microcontroller, MPU6000 sensor, SPI interface connection, faster computing speed;
5.Support 2-4S power input;
6.Built-in 5V 1A output BEC;
7.Support SBUS/PPM/DSMX and other mainstream receiver market;
8.Buzzer / programming LED/ voltage monitoring, /BLHELI electro modulation programming
The flight control is used to assemble about 80-90 small shafts, the motor chooses 1104 7500KV, and the battery is about 2S 400-500MAH. The blade uses 3 blades or 4 leaves of 2 oars. The receiver then recommends the purchase of a micro receiver (FRSKY, FLYSKY, DSM2, fly micro receiver). Try to be the lightest and simplest! Graph transmission select 25-200 adjustable integration diagram transmission, but the map transmission must be connected to the power supply
Omnibus F3 (integrated OSD) Mini flight control parameter:
A, equipped with MPU6000 F3 flight acceleration response faster; integrated 5V/1A BEC, integrated OSD. (this version is 6DOF, no barometer and electronic compass)
Product size: 27x27x5mm/1.1×1.1×0.2inch
Net weight: 3g
The current mainstream F4 flight control, flight control and integrated OSD function, OSD program is integrated in a MCU, without additional SCM OSD, and the OSD parameter adjustment and flight control software is also adjustable integrated with the microcontroller through the SPI bus DMS mode control OSD chip, faster, input and output using standard equipment interface. To reduce the conversion of wires and connectors, reduce bad line risk, improve the assembling and maintenance convenience, the MPU6000 sensor and connected by SPI bus, improve the sensor sampling rate, improve the operating frequency of MCU master program, provides higher precision and faster response speed. Input voltage 2S-4S, output current of 1A with BEC-5V, support the market mainstream PPM, SBUS, DSM2/DSMX receiver. LED_STRIP interface, active buzzer interface. LC filter, with its own black box 128Mb Flash (16M Byte), to support the latest DSHOT tune. Betaflight online tuning,
The flight control for the assembly of the four axis is about 80-90, the 1104 7500KV motor, the battery is about 400-500MAH 2S. The blade uses 3 blades or 4 leaves of 2 oars. Graph transfer selection 25-200 adjustable integrated graphic transmission.
Omnibus F4 (integrated OSD) Mini flight control parameter:
Sensor: MPU-6000 three accelerometer / three axis gyro (SPI connection)
Power supply: 2-4S battery input
BEC: built-in 5V/1A
Receiver: Sbus or Spektrum serial interface of RX, 1024/2048, SBUS, XBUS, SumD and SumH RX built-in reverser
Support 3.3V Spektrum satellite receiver
Support PPM receiver
Support programmable LEDSD (turn off Transponder before use)
Support BLheli suite ESC programming
Built in voltage detection and alarm
1. Specially designed for small traversing machine, suitable for the following sizes of 280mm frame, especially 130mm internal frame, can play small and functional advantages;
2. This board provides all the functions with a weight of 3g, size only 27*27MM, and a fixed hole of 20MM (M2.5 hole);
3. Designed for four axis models, built in LC filter, support BF firmware (Omnibus, F3 firmware);
4. The use of STM32F405RGT6 microcontroller, MPU6000 sensor, SPI interface connection, faster computing speed.
5. Support 2-4S power input.
6. Built-in 5V 1A output BEC.
7. Support SBUS/PPM/DSMX and other mainstream receiver market;
8. Buzzer / programming LED/ voltage monitoring, /BLHELI electro modulation programming.
9. Color: Black
10. Product size: 27x27x6mm/1.1×1.1×0.2inch
11. Net weight: 3g
