1pcs Beitian BN 880 GLONASS Flight Control Dual GPS Module for APM PIX4 Ublox NEO M8N
Click to see details
1pcs Beitian BN 880 GLONASS Flight Control Dual GPS Module for APM PIX4 Ublox NEO M8N

1pcs Beitian BN-880 GLONASS Flight Control Dual GPS Module for APM PIX4/Ublox NEO-M8N BN-800 GPS Module For Pixhawk APM

100 % of buyers enjoyed this product!
Availability: in stock
TODAY'S DEAL Ends in: 04:36:18
Price:  $ 20.12 / piece
Sale Price:  $ 18.71 / piece
from AliExpress
45 days Money back 45 days Money back Returns accepted if product not as described, buyer pays return shipping; or keep the product & agree refund with seller.
On-time Delivery On-time Delivery
Guarantees: On-time Delivery 60 days

Sort By

Top-rated Seller

Share:

Beitian BN-880 GLONASS Flight Control Dual GPS Module for APM PIX4/Ublox NEO-M8N BN-800 GPS Module For Pixhawk APM

BN-880 GPS Module:

Features:

GPS Module,Dual Module Compass With electronic compass IC HMC5883L 1.25mm spacing between the 6pins patch seat Specifications: Model: BN-880 Power Supply: DC Voltage 2.8V-6.0V,Typical:3.3V or 5.0V Consumption: Capture [email protected] Receiving Format: GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS Receiving Channel: 72 Searching Channel Receiving Sensitivity: Trace -167dBm Capture-148dBm Positioning Time:Cold Start: avg 26s Warm Start: avg 25s Hot Start: avg 3s Level Positioning Precison: 2m At Open Wind Output Frequency: 1Hz-10Hz,Default 1Hz Speed Precison: 0.1 m/s (Without Aid) Acceleration Precison: 0.1 m/s (Without Aid) Dynamic Characteristics: Max Height:18000m Max Speed: 5153m/s Max Acceleration: 4G UART Interface: UART Port:TXDA and RXDA Support Rate: 4800bps to 115200bps,Default 9600dps Working Temperature: -40-+85(Degree) Storage Temperature: -40-+85(Degree) The Module’s Pins: SDA,GND,TX,RX,VCC,SCL Size: 28 x 28 x 10mm/1.1 x 1.1 x 0.4 inch Package size: 100 x 69mm/3.9 x 2.7 inch Weight: 14g Package weight: 16g Note: Can not use for flight control with SCM,but it is suitable for Open source flight controller. Package Include: 1 x Dual GPS Module 1 x sticker 1 x cable set

BN-800 GPS Module:

Features:

With U-blox M8

Can simultaneously acquire and track different GNSS (Global Navigation Satellite) system,parallel to receive GPS (QZSS) and GLONASS or BeiDou, or while receiving GLONASS and BeiDou.

Specially adapted to the needs to the highest availability and accuracy of high-performance applications,even if is in the GPS signal poor environment.

Equipped with a built-in intelligent automatic switching function.

With long Offline A-GNSS (GPS and GLONASS) function.

Support GPS + BeiDou

Can run simultaneously GPS + GLONASS or GPS +BeiDou

With GPS antenna

Low power consumption

Fast positioning speed

Search to more number of satellites and high positioning accuracy

Specifications:

Item Name:GPS Module

Model:BN-800

Gps Chip parameters:

Receiver type 72-channel u-blox M8 engine

SBAS L1 C/A: WAAS, EGNOS, MSAS

Galileo-ready E1B/C (NEO-M8N)

Nav. update rate1 Single GNSS: up to 18 HZ

Concurrent GNSS: up to 10 Hz

Position accuracy2 2.0 m CEP

Acquisition2 Cold starts: 26 s

Aided starts: 2 s

Reacquisition: 1.5 s

Sensitivity2 Tracking & Nav: –167 dBm

Cold starts: –148 dBm

Hot starts: –156 dBm

Power Supply:DC Voltage 2.8V-6.0V,Typical: 3.3V or 5.0V

Consumption:Capture [email protected]

Receiving Format:GPS,GLONASS,Galileo,BeiDou,QZSS and SBAS

Receiving Channel:72 Searching Channel

Receiving Sensitivity:Trace -167dBm

Capture-148dBm

Positioning Time:Cold Start:avg26s

Warm Start:avg25s

Hot Start:avg3s

Level Positioning Precison: 2m At Open Wind

Output Frequency: 1Hz-10Hz,Default 1Hz

Speed Precison: 0.1 m/s (Without Aid)

Acceleration Precison: 0.1 m/s (Without Aid)

Dynamic Characteristics: Max Height:18000m

Max Speed:515m/s

Max Acceleration:4G

UART Interface:UART Port: TXDA and RXDA

Support Rate:4800bps to 115200bps,Default 9600dps

Working Temperature:-40-+85

Storage Temperature:-40-+85

Size: 35 x 35 x 6mm/1.4 x 1.4 x 0.2 inch

Package size: 100 x 70mm/3.9 x 2.8 inch

Net weight: 12g

Package weight: 14g

Notice:

Cable supports mini APM,if it is used for version 2.6 or 2.8,GPS of Pixhawk is needed to change the cable by yourself.

It Can not use for flight control with SCM,but it is also suitable for Open source flight controller.

Package Include:

1 x GPS Module

1 x sticker

1 x cable set
